Cov txheej thickness cuam tshuam li cas rau qhov ruaj ntawm pogo pin connector?
1. Pogo pin connector ua haujlwm stroke xaiv
Lub pogo pin connector raug xaiv raws li qhov chaw khoom thiab ua haujlwm stroke ntau. Yog tias qhov chaw me me dhau lawm, lub caij nplooj ntoos hlav ntawm pogo pin connector yuav compressed heev, uas yuav cuam tshuam rau lub neej kev pab cuam. Yog tias qhov chaw loj dhau, nws yuav ua rau kev sib cuag tsis zoo, impedance tsis ruaj khov, thiab cov duab tam sim ntawd txiav tawm.
2. Kev xaiv cov khoom siv plating
Cov khoom siv electroplating ua lub luag haujlwm hauv kev txhim kho conductivity, tiv thaiv oxidation, thiab tiv thaiv hnav rau pogo pin connector. Qhov tseeb, cov khoom sib txawv ua haujlwm sib txawv. Piv txwv li, kub muaj hluav taws xob conductivity zoo heev. Yog li ntawd, rau high-tam sim no connectors, cov khoom uas muaj impedance siab feem ntau xaiv electroplated kub.
3. Kev cuam tshuam ntawm lub thickness ntawm txheej
Thaum lub sijhawm ua haujlwm ntawm pogo tus pin connector, yuav muaj qee qhov kev sib txhuam thiab hnav vim kev sib cuag, yog li lub thickness ntawm txheej muaj kev cuam tshuam zoo rau kev pab cuam lub neej ntawm cov khoom. Thaum siv rau ib qho twg, cov txheej yuav raug hnav, thiab qhov kev tiv thaiv yuav loj heev thiab impedance yuav tsis ruaj khov. Cov txheej txheej ntawm 100,000-lub sij hawm pogo tus pin yuav twv yuav raug ua kom tuab dua li ntawm 10,000-lub sij hawm pogo tus pin, yog li thaum xaiv cov khoom, nws yuav tsum tau plated raws li qhov tseeb.
4. Qhov cuam tshuam ntawm elasticity
Lub zog tiv tauj ntawm lub caij nplooj ntoos hlav connector los ntawm lub caij nplooj ntoos hlav sab hauv. Lub caij nplooj ntoos hlav quab yuam ncaj qha cuam tshuam rau qhov tsis kam thiab ruaj khov ntawm lub caij nplooj ntoos hlav. Yog tias lub zog elastic loj dhau lawm, qhov sib txhuam coefficient yuav nce, uas yuav cuam tshuam rau lub neej kev pab cuam ntawm lub caij nplooj ntoos hlav.
