High tam sim no them pogo tus pin POGOPIN tam sim no mus txog 15A
Lub Hoobkas tau tsim nyob rau xyoo 2008, nrog rau ntau yam tsis siv neeg tshuab dhos, tshuab dhos, thiab lwm yam khoom siv, tshwj xeeb hauv kev tsim thiab muag ntawm pogo pin charging pins, roj teeb pins, kav hlau txais xov pins, thiab lwm yam pogo pins thiab connectors. Kev sib cuag muaj zog thiab kev ua haujlwm ruaj khov.
pogo pin khoom kev ua tau zoo
1.0 Txheej txheem cej luam
Qhov kev qhia tshwj xeeb no txhais cov kev ua haujlwm tsis zoo thiab cov kev xeem yuav tsum tau ua ntawm tus pin pogo.
2.0 Kev xav tau
2.1 Dimensions
Tag nrho qhov ntev yuav tsum ua raws li cov khoom yuav tsum tau kos duab.
2.2 Cov khoom siv thiab electroplating
Lub cev yog tooj dag, npib tsib xee plated 50u" kub plated 1-3 u".
Lub plunger yog tooj dag, npib tsib xee plated 50u" kub plated 1-3 u".
Lub caij nplooj ntoos hlav yog kub-plated stainless hlau.
3.0 Parameters
3.1 Kev ua haujlwm tsis tu ncua: 1.5a
3.2 Ua haujlwm voltage: qis dua 12v @ 25 degree
3.3 Kev pab lub neej: 10000 zaug
3.4 Ua hauj lwm tus pas ntsuas kub: -25 degree -75 degree 90 feem pua rhmax
3.5 Cia kub: -40 degree -85 degree 90 feem pua rhmax
4.0 Cov khoom hluav taws xob
4.1 Kev tiv thaiv tiv thaiv Kev tiv thaiv tiv thaiv ntawm qhov chaw ua haujlwm yog<25mohm>
4.2 Insulation resistance with plastic under the condition of 500v dc or ac for one-minute insulation resistance>100m
4.3 Tiv thaiv qhov hluav taws xob 500ac 1 feeb, qhov dej ntws loj tam sim no 0.3ma
5.0 Mechanical Properties
5.1 Ib txwm quab yuam Lub ntsiab lus ua haujlwm yog ntau dua 60gf
5.2 Tuav quab yuam 1kg / tus pin
5.3 Durability 10, 000 lub sij hawm lub caij nplooj ntoos hlav quab yuam yog khaws cia nyob rau hauv qhov ntau
5.4 Kev co tsis kam 10 ~ 500hz vibration zaus rau 15 feeb, 1.2mm amplitude, tsis ntau tshaj sec. Fais fab tuag, tiv thaiv impedance<>
6.0 Kev ua haujlwm ib puag ncig
6.1 Thermal shock -40 degree 30min.85 degree / 30min.100 cycles, tiv tauj impedance<100mohm without="" appearance="">
6.2 Moisture resistance 90～95%r.h,60℃, measure insulation after 500hours>100mohm, tiv tauj impedance<100mohm, no="" appearance="">
6.3 Tshuaj tsuag ntsev 5 feem pua cov tshuaj ntsev tsis muaj xeb rau 24 teev.
6.4 Solderability test 230 ± 5 degree ± 1seconds ntub vuam kev pab them nqi ntawm ntau tshaj 95 feem pua.
