Feem ntau siv roj teeb connectors yog nyob rau hauv ob daim ntawv: pogo pins thiab shrapnel connectors. Cov roj teeb txuas uas tau siv dav hauv cov xov tooj ntawm tes yog pogo pins. Piv nrog rau lub caij nplooj ntoos hlav-hom roj teeb connectors, lawv muaj qhov zoo li cas? Vim li cas pogo pins zoo dua shrapnel?
Piv nrog rau shrapnel hom connector ntawm tib qhov loj, lub pogo pin connector muaj ib tug loj npaum li cas ntawm compression thiab ruaj khov kev sib cuag. Lub pogo pin roj teeb connector muaj kev ua haujlwm zoo dua compression ntau dua li hom shrapnel, kom ntseeg tau tias kev ruaj ntseg ntawm kev sib txuas.
Muab piv cov pogo tus pin thiab shrapnel hom nrog tib tus nqi ntawm compression, lub pogo pin connector occupies tsawg PCB board chaw. Nrog rau txoj haujlwm ua haujlwm ntawm 4mm thiab compression ntawm 1mm, lub pogo pin connector siv qhov chaw tsawg dua ntawm PCB pawg thawj coj saib. Lub thinning thiab miniaturization ntawm lub cev tuaj yeem pom tau.
Thaum compressed, txoj hauj lwm ntawm qhov chaw sib cuag ntawm pogo pin connector tseem tsis hloov, uas tuaj yeem tswj tau qhov kev sib txuas ruaj khov thiab tau txais hluav taws xob ruaj khov. Tus pin pogo yog 20,000 zaug, thiab hom shrapnel yog 5,000 zaug. Lub durability ntawm pogo pin charging connector muaj zog dua li ntawm cov shrapnel hom. Cov duab ntawm cov yas gel thiab kev sib xyaw ua ke ntawm cov thimble tuaj yeem tsim kev ywj pheej, yog li kev ywj pheej ntawm kev tsim yog qhov tseem ceeb.
