Dab tsi yuav tsum tau them sai sai rau thaum soldering pogo pins?
Zoo li feem ntau cov khoom sib txuas, pogo pins muaj qee qhov ntsuas kub tsis kam. Cov txheej txheem tseem ceeb thiab cov khoom siv caij nplooj ntoos hlav tsis tuaj yeem tiv taus cua sov lossis ib zaug tin reflow txheej txheem. Yog tias koj npaj yuav rov ua haujlwm dua, thov hu rau peb thiab peb yuav pab koj xaiv qhov kev sojntsuam thiab cov khoom siv uas ua tau raws li koj xav tau, kom tsis txhob muaj teeb meem tom qab.
Yuav ua li cas koj tsim ib tug Circuit Court board (PCB) loj rau ib tug pogo pin connector?
Feem ntau hais lus, lub vojvoog nyob deb ntawm lub rooj tsavxwm Circuit Court yuav tsum tau tshwj tseg ntau dua {{0}}}.3mm ntawm qhov kawg ntawm tus pin pogo, lub vojvoog ntawm cov nplaum nplaum nplaum yuav tsum tau tshwj tseg ntau dua {{4} }.4mm rau lub nplhaib convex, thiab qhov ntev ntawm tus Tsov tus tw kawg yuav tsum yog tsawg kawg yog 0.4mm ntau tshaj qhov thickness ntawm lub rooj tsavxwm Circuit Court. Tab sis tau kawg, cov ntaub ntawv saum toj no yuav tsum ua raws li qhov tsim nyog sab hauv siab ntev thiab qhov tsawg kawg nkaus ib rab koob sib nrug.
Yuav ua li cas los tsim lub rooj tsav xwm hloov tau yooj yim (FPC) qhov ntev rau pogo pin connectors?
Nws tsis txawv ntau npaum li cas ntawm lub rooj tsavxwm dav dav. Qhov sib txawv loj tshaj plaws yog tias tom qab txiav tawm lub rooj tsav xwm hloov tau yooj yim, ib qho ntxiv 0.1 hli yuav tsum tau tshwj tseg ntawm tus Tsov tus tw ntawm ib rab koob.
Yuav ua li cas loj ib lub rooj tsavxwm Circuit Court (PBC) rau soldering pogo pin connectors?
Rau ib feem nyob rau hauv kev sib cuag nrog lub solder paste, ib tug ntxiv pogo pin vojvoog ntawm 0.5mm yuav tsum tau tseg.
