Dip Spring-loaded Pogo Pin
Dual-in-line pob pogo pins (Lus Askiv: dual in-line pob), tseem hu ua DIP pob lossis DIP pob, abbreviated li DIP lossis DIL, yog ib txoj hauv kev ntim rau kev sib xyaw ua ke. Cov duab ntawm lub integrated circuit yog ib daim duab plaub. Muaj ob kab sib luag ntawm cov hlau pins ntawm sab, hu ua pogo pin headers. DIP-packed Cheebtsam tuaj yeem raug soldered rau hauv plated los ntawm qhov ntawm lub rooj tsavxwm luam tawm, lossis muab tso rau hauv DIP qhov (sockets).
Dip Spring-loaded Pogo Pin
Lub DIP pogo pin ntim CPU nti muaj ob kab ntawm tus pins uas yuav tsum tau muab tso rau hauv lub qhov (socket) nti nrog tus qauv DIP. Ntawm chav kawm, nws tseem tuaj yeem muab tso ncaj qha rau hauv lub rooj tsav xwm hauv Circuit Court nrog tib tus lej ntawm cov qhov thiab cov qauv geometric rau soldering. DIP-packed chips yuav tsum tau ntsaws thiab tshem tawm ntawm lub qhov (socket) nrog kev saib xyuas tshwj xeeb kom tsis txhob muaj kev puas tsuaj rau cov pins. DIP pob qauv cov ntaub ntawv yog ntau txheej ceramic DIP DIP, ib txheej txheej ceramic DIP DIP, txhuas ncej DIP (xws li iav-ceramic sealing hom, yas ntim qauv hom, ceramic low melting iav ntim hom) Tos.
Dip Spring-loaded Pogo Pin
Cov pob DIP uas nquag siv tau ua raws li JEDEC tus qauv, thiab lub suab (pitch) ntawm ob tus pins yog {{0}}.1 nti (2.54 mm). Qhov kev ncua deb ntawm ob kab ntawm tus pins (kab qhov sib nrug, kab sib nrug) nyob ntawm tus naj npawb ntawm cov pins, feem ntau yog 0.3 ntiv tes (7.62 hli) lossis 0.6 ntiv tes (15.24 hli. ). Lwm qhov nrug tsawg dua yog 0.4" (1{{20}}.16mm) lossis 0.9" (22.86mm), thiab qee qhov pob khoom muaj 0.07" (1.778mm) suab thiab 0.3", 0.6" lossis 0.75" kab sib nrug.
DIP-pogo pin pob khoom siv nyob rau hauv yav dhau los Soviet Union thiab Eastern European lub teb chaws yog kwv yees ze rau JEDEC tus qauv, tab sis siv metric 2.5 hli suab es tsis txhob ntawm imperial 0.1 ntiv tes (2.54 hli).
Tus naj npawb ntawm tus pins hauv pob DIP yog ib txwm muaj tus lej sib npaug. Nrog {{0}}.3" kab sib nrug, 8 mus rau 24 tus pin suav yog sib koom ua ke, thiab pob khoom nrog 4 lossis 28 tus pins qee zaus pom. Cov pins sib koom yog 24, 28, 32, lossis 40 yog kab qhov sib nrug yog 0.6 ntiv tes, thiab cov pob khoom nrog 36, 48, lossis 52 tus pins kuj muaj. CPUs xws li Motorola 68000 thiab Zilog Z180 muaj tus lej suav ntawm 64, uas yog tus lej siab tshaj plaws suav rau ib pob DIP uas nquag siv.
