Yuav ua li cas xaiv ib tug pogo pin connector?
Dab tsi yog kev ceev faj rau kev xaiv pogo pin connectors? Nrog txoj kev loj hlob sai ntawm cov cuab yeej technology, cov xov tooj ntawm tes tau dhau los ua nyias thiab sib dua. Kev them nyiaj ceev tau nce qhov kev thov rau cov khoom sib txuas siab tam sim no, thiab daim ntawv thov ntawm pogo pin connectors (caij nplooj ntoos hlav thimble connectors) tau ua ntau zaus. Tam sim no, cov khoom siv digital ntse ntawm kev ua lag luam pib siv pogo pin connectors, thiab tsuas yog ob peb yam khoom qis kawg nkaus xwb tseem yuav siv shrapnel-type connectors;
Pogo tus pin connector ua haujlwm stroke xaiv:
Kev xaiv ntawm pogo pin connector yuav tsum tau txiav txim siab raws li cov khoom siv, thiab ib qho nyob rau hauv kev ua haujlwm stroke yuav tsum raug xaiv; Qhov chaw me me yuav dhau-compress lub caij nplooj ntoos hlav ntawm pogo pin connector, cuam tshuam rau lub neej kev pab cuam, thiab ntau qhov chaw yuav ua rau kev sib cuag tsis ua hauj lwm Thaum nws nyob rau hauv qhov chaw, lub impedance tsis ruaj khov thiab tam sim ntawd disconnected.
Kev xaiv cov khoom siv plating:
Electroplating cov ntaub ntawv nyob rau hauv pogo pin connectors tuaj yeem txhim kho conductivity, tiv thaiv oxidation, hnav tsis kam, thiab lwm yam. Cov ntaub ntawv sib txawv muaj cov haujlwm sib txawv. Kub muaj hluav taws xob conductivity zoo. Nws yog feem ntau yog siv rau high-tam sim no connectors thiab cov khoom uas muaj impedance siab. Xaiv electroplated kub.
Dab tsi yog qhov cuam tshuam ntawm plating zaj duab xis thickness:
Pogo tus pin connector yuav hnav tawm vim kev sib cuag kev sib txhuam ntev ntev thaum ua haujlwm. Lub thickness ntawm electroplating zaj duab xis muaj kev cuam tshuam zoo rau lub neej kev pab cuam ntawm cov khoom. Thaum siv rau qee qhov kev txwv, txheej txheej electroplated yog hnav, thiab qhov kev tiv thaiv yuav loj dhau, thiab impedance yuav tsis ruaj khov. Cov txheej txheej electroplating ntawm 100,000 zaug pogo pin yog tuab dua li ntawm 10,000 zaug. Yog li ntawd, cov txheej txheem electroplating yuav tsum raug xaiv raws li qhov xav tau thaum xaiv cov khoom.
Lub zog ntawm elasticity:
Lub zog tiv tauj ntawm pogo pin connector los ntawm lub caij nplooj ntoos hlav sab hauv. Lub zog elastic ntawm lub caij nplooj ntoos hlav muaj qhov cuam tshuam ncaj qha rau lub impedance ntawm pogo tus pin; ntau elastic quab yuam yuav ua rau kom muaj kev sib txhuam coefficient thiab cuam tshuam rau lub neej kev pab cuam ntawm tus pin pogo.
