Pogo pin caij nplooj ntoos hlav pins nruab rau PCB li cas?
POGO PIN yog ib qho khoom siv hluav taws xob feem ntau siv. Nws cov qauv yooj yim muaj xws li ib rab koob tig, ib rab koob tig, thiab lub caij nplooj ntoos hlav compression. Lub qhov ncauj ntawm lub koob raj yog crimped kom lub koob nyob rau hauv lub koob raj, thiab kev sib cuag quab yuam yog muab los ntawm lub caij nplooj ntoos hlav los tsim kom muaj kev sib txuas hluav taws xob ntawm rab koob thiab qhov chaw docking. Kuv ntseeg tias ntau tus neeg tsis paub yuav ua li cas POGO PIN yog welded. Cia peb kawm seb yuav ua li cas POGO PIN connector yog soldered ntawm PCB?
Nrog rau txoj kev loj hlob ntawm kev ua lag luam thiab kev kho dua tshiab ntawm cov khoom, ntau thiab ntau tus neeg siv khoom tsis yog tsuas yog txwv rau ntau qhov kev ua haujlwm ntawm cov khoom, tab sis kuj xav tau fashionable tsos thiab me me thiab nyias. POGO PIN yog qhov kev sojntsuam zoo heev, thiab nws qhov ntim tuaj yeem me me, yog li nws tuaj yeem txo qhov hnyav ntawm cov khoom sib txuas, txuag chaw, thiab muaj qhov zoo nkauj zoo nkauj thaum siv hauv cov khoom sib txuas.
Hauv kev ua haujlwm txhua hnub, muaj ntau tus neeg nug, yuav ua li cas siv POGO PIN ntawm cov khoom, yuav ua li cas rau solder rau PCB board, qhov tseeb, thaum siv POGO PIN, cov txiv neej thiab poj niam xaus yog docked thiab pogo. tus pin compresses ib qho mob stroke (tus nqi compression yog 1.0mm). , elastic quab yuam 70g ± 20g). Nws tuaj yeem siv rau, xa cov teeb liab, thiab lwm yam kom ua tiav ntau yam haujlwm.
POGO PIN tuaj yeem raug soldered ntawm PCB los kho nws, lossis nws tuaj yeem kho tau ntawm cov qauv khoom, uas yuav tsum muaj cov kws tsim qauv tsim los daws qhov teeb meem. Thiab peb tuaj yeem pab koj tiag tiag, nrog 10 xyoo dhau los ntawm kev tsim POGOPIN caij nplooj ntoos hlav thimbles, nrog rau cov khoom zoo thiab ntau. Txhawm rau kom ntseeg tau tias cov khoom lag luam zoo, cov ntsiab lus ntawm txhua qhov kev sib txuas yuav tsum tau tswj hwm zoo heev. Lub caij nplooj ntoos hlav thimbles peb tsim tau ib txwm tswj hwm tus thawj coj, tau lees paub los ntawm qee lub tuam txhab paub zoo hauv tsev thiab txawv teb chaws raws li lawv cov khoom sib txuas, thiab tau tsim lub koob npe nrov.
Pogo tus pin pogo pins ntsia rau PCB li cas?
Ua ntej, nto mount
Lub pogo tus pin feem ntau yog ntsia tau rau hauv txoj kev ruaj khov, thiab hauv qab ntawm lub koob raj yog ib qho qauv hauv qab, yog li peb tuaj yeem siv lub pob ntsug lossis kab rov tav, uas ua rau nws yooj yim dua rau solder nrog PCB. Tsis tas li ntawd, qee cov koob muaj qhov chaw pins ntawm qhov kawg kom tsis muaj qhov offset thiab nws yuav ua haujlwm zoo dua.
Thib ob, txoj kev ncaj nraim soldertail installation txoj kev
Ordinary plug-in pob rau yooj yim soldering. Tsis tas li ntawd, peb feem ntau siv tail-end plug-in tej pob khoom, uas kuj muab pogo pin manufacturers ntau txoj kev xaiv nyob rau hauv cov nqe lus ntawm kev siv qhov chaw.
Thib peb, floating installation
Feem ntau yog siv ob lub taub hau ob-ua yeeb yam tsim, uas yog qhov tsim nyog rau kev sib txuas yam tsis muaj vuam siab, tso cai rau cov engineers kom muaj qhov chaw yooj yim dua thaum ua ob txoj kev sib txuas ntawm lub rooj tsavxwm.
Cov ntsiab lus saum toj no yog ob peb txoj kev teeb tsa ntawm pogo pin caij nplooj ntoos hlav thimble pom zoo rau koj hnub no. Muaj ntau ntau lwm txoj kev teeb tsa rau pogo pin caij nplooj ntoos hlav thimble, peb tseem xav tau xaiv raws li peb qhov xwm txheej tiag tiag.
